GH4169 Nickel Alloy for High Temperature Application ranges
-253°C~650°C
GH4169 has high strength, good toughness and has good corrosion
resistance in high and low temperature environment. The supply
state can be solid solution treatment or precipitation hardening
state.
Long term working temperature range: -253°C~650°C. Short time
working temperature up to 800°C.
Chemical composition
| Element | C | Cr | Ni | Co | Mo | Al | Ti | Fe |
| Weight(%) | 0.08 max | 17.00~21.00 | 50.00~55.00 | 1.00 max | 2.80~3.30 | 0.20~0.80 | 0.65~1.15 | Rem |
| Element | Nb | B | Mg | Mn | Si | P | S | Cu |
| Weight(%) | 4.75~5.50 | 0.006 max | 0.010 max | 0.35 max | 0.35 max | 0.015 max | 0.015 max | 0.300 max |
Advantages
- Good mechanical properties – tensile, fatigue and creep-rupture
- Yield tensile strength, creep, and rupture strength properties are
exceedingly high
- Highly resistant to chloride and sulfide stress corrosion cracking
- Resistant to aqueous corrosion and chloride ion stress corrosion
cracking
- High temperature resistant
- Age-hardenable with a unique property of slow aging response that
permits heating and cooling during annealing without the danger of
cracking.
- Excellent welding characteristics, resistant to postweld age
cracking
Application
- Turbine disk, ring, casing, shaft, blade, fastener, elastic
element, gas pipe, sealing element and welded structural
components, etc.
- Turbine rotor in liquid hydrogen and liquid oxygen rocket engines.
- Various elastic components and grillage used in nuclear industry;
- A variety of components used in the petroleum and chemical
industries.
