Nimonic 90 Precipitation Hardenable Ni-Cr-Co Alloy with High
Strength
Introduction
Nimonic 90 is a precipitation-hardenable nickel-chromium-cobalt
alloy having high stress-rupture strength and creep resistance at
temperatures to about 1700°F (920°C). Nimonic 90 also has good
resistance to high-temperature corrosion and oxidation. Nimonic 90
is used for blades and discs in gas turbines, hot-working tools,
and springs.
Characters
- High stress rupture strength and high creep resistance at high
temperatures
- Good resistance to high-temperature corrosion and oxidation
- Age-hardenable
- High temperature dynamic applications
Application
The alloy is used for turbine blades, discs, forgings, ring
sections and hot-working tools. Also used to make Aerospace
fasteners.
Chemical composition
C≤0.13, Cr=18.00~21.00, Co=15.00~21.00, Al=1.00~2.00, Ti=2.00~3.00,
Fe≤1.50, Zr=≤0.0150, B≤0.020, Si≤0.80, Mn≤0.40, S≤0.015, P≤0.020,
Cu≤0.200, Ni=Remainder
Typical Mechanical Properties – Spring Applications
Solution Treated
Heat Treatment: 1922 - 2012°F (1050 - 1100°C) + WQ
Tensile Strength: 157 ksi max; (1080 MPa) max
Spring Temper
Heat Treatment: As supplied condition.
Tensile Strength: 189 - 223 ksi; (1300-1540 MPa)
Spring Temper + Aged
Heat Treatment: After spring coiling. Age: 1202°F (650°C) for 4
hours. Alternatively, Age at 1112°F(600°C) for 16 hours and air
cool.
Tensile Strength: 189 – 260 ksi; (1300 – 1800 MPa)
Suggested Operating Conditions: Optimum stress and low relaxation
at temperatures up to 700°F (371°C)
Solution Treated + Aged
Heat Treatment: After spring coiling: Solution Heat Treat: 1976°F
(1080°C) followed by rapid cooling + Age at 1382°F (750°C) for 4
hours and air cool. Alternatively, Age at 1292°F (700°C) for 16
hours and air cool
Tensile Strength: 145 - 203 ksi; (1080 - 1400 MPa)
Suggested Operating Conditions: Optimum resistance to relaxation at
temperatures up to 1112°F (600°C)
